Specificaties
Bekijk de belangrijkste eigenschappen en technische details van dit product.
Geheugen
| Ondersteunde geheugen types | DDR4-SDRAM |
| Aantal geheugenslots | 8 |
| Geheugen slots type | DIMM |
| Geheugen kanaal | Vierkanaals |
| Non-ECC | Ja |
| Supported memory clock speeds | 2133,2400,2666,2800,2933,3000,3200,3300,3333,3400,3466,3600,3733,3800,3866,4000,4133,4266 MHz |
| Maximum intern geheugen | 256 GB |
| Niet gebufferd geheugen | Ja |
Processor
| Processorfabrikant | Intel |
| Processor socket | LGA 2066 (Socket R4) |
| Compatibele processors | Intel® Core™ X-series |
| Max. aantal SMP-processoren | 1 |
| Supported processor sockets | LGA 2066 |
Interne aansluitingen
| USB 2.0 aansluitingen | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen | 2 |
| Aantal SATA III connectors | 8 |
| Aansluiting voor audiopaneel aan voorzijde | Ja |
| Voorpaneel-connector | Ja |
| Aansluitingen voor EATX voedingen | 1 |
| Aansluiting voor CPU koeler | Ja |
| Aansluitingen voor behuizingsventilatoren | 2 |
| 12V vermogen-connector | Ja |
| RGB LED-aansluitrail | Ja |
Aansluitingen achterzijde
| Aantal USB 2.0-poorten | 4 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A | 3 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type C | 1 |
| Aantal Ethernet LAN (RJ-45)-poorten | 1 |
| Hoofdtelefoonuitgangen | 1 |
| Microfoon, line-in ingang | Ja |
| S/PDIF-uitgang | Ja |
| Digitale audio, optische uitgang | 1 |
| WiFi-AP antenna jack | 1 |
Netwerk
| Ethernet LAN | Ja |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| LAN controller | Realtek RTL8125-CG |
| Wake-on-LAN | Ja |
| Wi-Fi | Ja |
| Wi-Fi-standaarden | Wi-Fi 6 (802.11ax) |
| Bluetooth | Ja |
| Bluetooth-versie | 5.0 |
Grafisch
| Ondersteuning voor parallel processing | 2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, 3-Way SLI |
Uitbreidingsmodules
| PCI Express x1 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 16 |
BIOS
| BIOS type | UEFI AMI |
| Grootte BIOS-geheugen | 128 Mbit |
| ACPI version | 6.2 |
| Clear CMOS jumper | Ja |
| Systeem Management BIOS (SMBIOS) versie | 3.2 |
Opslag-controllers
| Ondersteunde types opslag-drives | HDD & SSD |
| Ondersteunde opslagstationinterfaces | PCI Express 3.0, SATA |
| Maximum aantal HDD's per behuizing | 8 |
| Soorten RAID | 0, 1, 5, 10 |
Kenmerken
| Component voor | PC |
| Moederbord form factor | ATX |
| Moederbord chipset familie | Intel |
| Chipset moederbord | Intel® X299 |
| Audiochip | SupremeFX S1220A |
| Audio-uitgangskanalen | 8.0 kanalen |
| Type koeling | Actief |
| Type stroombron | ATX |
| Aantal montagegaten | 9 |
| Ondersteunt Windows | Windows 10 x64 |
Logistieke gegevens
| Code geharmoniseerd systeem (HS) | 84733020 |
Gewicht en omvang
| Breedte | 305 mm |
| Diepte | 244 mm |
Inhoud van de verpakking
| Meegeleverde drivers | Ja |
Overige specificaties
| HDD omvang | 2.5/3.5" |
| PCI Express x4 (Gen 3.x) slots | 1 |
| Inclusief hulpprogramma's | Ja |
