Specificaties
Bekijk de belangrijkste eigenschappen en technische details van dit product.
Geheugen
| Ondersteunde geheugen types | DDR4-SDRAM |
| Aantal geheugenslots | 4 |
| Geheugen slots type | DIMM |
| Geheugen kanaal | Dubbelkanaals |
| Supported memory clock speeds | 2133,2400,2666 MHz |
| Maximum intern geheugen | 64 GB |
Processor
| Processorfabrikant | Intel |
| Processor socket | LGA 1151 (Socket H4) |
| Compatibele processors | Intel® Celeron®, Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Pentium®, Intel® Xeon® |
Interne aansluitingen
| USB 2.0 aansluitingen | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1)-aansluitingen | 1 |
| ATX Power connector (24-pin) | Ja |
| COM aansluitingen | 1 |
| TPM connector | Ja |
Aansluitingen achterzijde
| Aantal USB 2.0-poorten | 2 |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A | 2 |
| Aantal poorten USB 3.2 Gen 2 (3.1 Gen 2) Type A | 2 |
| Aantal Ethernet LAN (RJ-45)-poorten | 2 |
| VGA (D-Sub)poort(en) | 1 |
| Aantal HDMI-poorten | 1 |
| DVI-D poorten | 1 |
| Hoofdtelefoonuitgangen | 1 |
| Microfoon, line-in ingang | Ja |
Netwerk
| Ethernet LAN | Ja |
| LAN controller | Intel® I210-AT, Intel I219LM |
Uitbreidingsmodules
| PCI Express x1 (Gen 2.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
Opslag-controllers
| Ondersteunde opslagstationinterfaces | SATA III |
Kenmerken
| Component voor | PC |
| Moederbord form factor | micro ATX |
| Moederbord chipset familie | Intel |
| Chipset moederbord | Intel C246 |
| Audio-uitgangskanalen | 8.0 kanalen |
Logistieke gegevens
| Code geharmoniseerd systeem (HS) | 84733020 |
Gewicht en omvang
| Breedte | 244 mm |
| Diepte | 244 mm |
| Hoogte | 73 mm |
Inhoud van de verpakking
| Meegeleverde kabels | SATA |
| Gebruikershandleiding | Ja |
Overige specificaties
| PCI Express x4 (Gen 3.x) slots | 1 |
| Maximum UDIMM geheugen | 64 GB |
| Gewicht | 577 g |
| Snelle installatiehandleiding | Ja |
