Specificaties
Bekijk de belangrijkste eigenschappen en technische details van dit product.
Beheerfuncties
| Switch type | Managed |
| Switch-laag | L3 |
| Quality of Service (QoS) | Ja |
Poorten & interfaces
| Aantal moduleslots SPF | 24 |
| Aantal moduleslots SPF+ | 4 |
| Console port | RJ-45 |
Netwerk
| Netwerkstandaard | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| 10G support | Nee |
| IP routing | Ja |
| Datastroombeheer | Ja |
| Verbindingsaggregatie | Ja |
| Broadcast stormbeheer | Ja |
| Spanning tree protocol | Ja |
| VLAN=ondersteuning | Ja |
Multicast-functies
| Multicast-ondersteuning | Ja |
Data-uitwisseling
| MAC-adrestabel | 16384 entries |
| Switchingcapaciteit | 128 Gbit/s |
| Throughput | 96 Mpps |
| Latentie (1 Gbps) | 5 µs |
| Latentie (10 Gbps) | 1,5 µs |
| Packet buffergeheugen | 1,5 MB |
Beveiliging
| DHCP-functies | DHCP server, DHCP client |
| Access Control List (ACL) | Ja |
| IGMP snooping | Ja |
Design
| Rack-montage | Ja |
| Vormfactor | 1U |
| Kleur van het product | Zwart |
Prestatie
| Type geheugen | SDRAM |
| Intern geheugen | 1024 MB |
| Flash memory | 128 MB |
| Geluidsniveau | 50,7 dB |
Energie
| Vermogenstoevoer inclusief | Nee |
Power over Ethernet (PoE)
| Power over Ethernet (PoE) | Nee |
Eisen aan de omgeving
| Temperatuur, in bedrijf | 0 - 45 °C |
| Temperatuur bij opslag | -40 - 70 °C |
| Relatieve luchtvochtigheid, in bedrijf | 10 - 90 procent |
| Luchtvochtigheid bij opslag | 5 - 95 procent |
| Warmtedissipatie | 204 BTU/h |
Gewicht en omvang
| Breedte | 440 mm |
| Diepte | 360 mm |
| Hoogte | 43,6 mm |
| Gewicht | 8 kg |
Logistieke gegevens
| Code geharmoniseerd systeem (HS) | 85176990 |
